12.12 Sales Accsoon Cineview HE Cineview SE Wireless HDMI SDI Video Transmitter & Receiver Kit 1200ft 350meter

Regular price
RM 1,839.00
Sale price
RM 1,839.00
Regular price
RM 1,900.00
Fast shipping | CXG
Fast shipping
Secure payments | CXG
Secure payments
Authentic products | CXG
Authentic products

Key Features

  • Wireless Video Transmitter/Receiver Set
  • Mix up to 4 Receivers, Tablets & Phones
  • 1080p60 HDMI Transmission up to 1200'
  • USB/UVC Output for Computer Streaming
  • iOS/Android App with Zebra & LUT Support
  • 2.4 & 5 GHz Dual Band Frequencies
  • 1.3" OLED Displays, >60ms Latency
  • DC/USB Power, L-Series Battery Support
  • Auto Channel Selection, Group Pairing
  • Fanless Design, Aluminum Construction

The CineView HE Multi-Spectrum Wireless Video Transmission System from Accsoon allows you to send a 1080p60 camera signal to the included receiver plus up to three mobile devices. This versatile wireless video transmission system provides a cost-effective way of allowing four people on set to monitor an HDMI camera signal. The transmitter can send signal to a total of four devices simultaneously over distances up to 1200' with only a 60ms delay. You can transmit to any mix of up to four receivers and iOS/Android smartphones and tablets using dual-band wireless signals.

The included dedicated receiver is easy to set up and pair, and it features an HDMI output and a USB UVC output to output your signal to a computer for streaming using third-party apps. The free-to-download companion app provides image tools such as peaking, zebras, false color for exposure, and .cube 3D LUT overlay. The transmitter and receiver feature DC and USB Type-C power inputs, and they also support an optional L-series battery that can power the set for up to 12 hours.


Specification

ProjectsTransmitter
Video InputSDI/HDMI
SDI Input Format1080p 23.98/24/25/29.97/30/50/59.94/60fps Level A/B
HDMI Input Format1080p 23.98/24/25/29.97/30/50/59.94/60fps
DC Port5.5mmx2.1mm center positive
DC Voltage7.4~16.8V
Audio44.1KHz/48KHz 16bit/24bit PCM
Latency<0.05s (Camera latency not included)
OLED Display1.3inch
Transmission Power17~20dBm
Transmission Range1200ft (No obstacles, no interference)
Power Consumption4.5Watt (Typical)
Operating Environment Temperature-10~40℃
Dimensions105mmx66mmx32mm (Antennas not included)
Weight210g (Antennas not included)
ProjectsReceiver
Video OutputSDI/HDMI
SDI Output Format1080p 24/25/30/50/60fps Level A
HDMI Output Format1080p 24/25/30/50/60fps
DC Port5.5mmx2.1mm center positive
DC Voltage7.4~16.8V
OLED Display1.3inch
Power Consumption3.5Watt (Typical)
Operating Environment Temperature-10~40℃
Dimensions105mmx66mmx32mm (Antennas not included)
Weight210g (Antennas not included)



In the Box

  • Accsoon CineView SE Multi-Spectrum Wireless Video Transmission System
  • CineView SE Transmitter
  • CineView SHE Receiver
  • Shoe Mount
  • Limited 1-Year Warranty
