12.12 Sales Accsoon Cineview HE Cineview SE Wireless HDMI SDI Video Transmitter & Receiver Kit 1200ft 350meter
- Regular price
- RM 1,839.00
- Sale price
- RM 1,839.00
- Regular price
-
RM 1,900.00
Share
Key Features
- Wireless Video Transmitter/Receiver Set
- Mix up to 4 Receivers, Tablets & Phones
- 1080p60 HDMI Transmission up to 1200'
- USB/UVC Output for Computer Streaming
- iOS/Android App with Zebra & LUT Support
- 2.4 & 5 GHz Dual Band Frequencies
- 1.3" OLED Displays, >60ms Latency
- DC/USB Power, L-Series Battery Support
- Auto Channel Selection, Group Pairing
- Fanless Design, Aluminum Construction
The CineView HE Multi-Spectrum Wireless Video Transmission System from Accsoon allows you to send a 1080p60 camera signal to the included receiver plus up to three mobile devices. This versatile wireless video transmission system provides a cost-effective way of allowing four people on set to monitor an HDMI camera signal. The transmitter can send signal to a total of four devices simultaneously over distances up to 1200' with only a 60ms delay. You can transmit to any mix of up to four receivers and iOS/Android smartphones and tablets using dual-band wireless signals.
The included dedicated receiver is easy to set up and pair, and it features an HDMI output and a USB UVC output to output your signal to a computer for streaming using third-party apps. The free-to-download companion app provides image tools such as peaking, zebras, false color for exposure, and .cube 3D LUT overlay. The transmitter and receiver feature DC and USB Type-C power inputs, and they also support an optional L-series battery that can power the set for up to 12 hours.
Specification
Projects | Transmitter |
---|---|
Video Input | SDI/HDMI |
SDI Input Format | 1080p 23.98/24/25/29.97/30/50/59.94/60fps Level A/B |
HDMI Input Format | 1080p 23.98/24/25/29.97/30/50/59.94/60fps |
DC Port | 5.5mmx2.1mm center positive |
DC Voltage | 7.4~16.8V |
Audio | 44.1KHz/48KHz 16bit/24bit PCM |
Latency | <0.05s (Camera latency not included) |
OLED Display | 1.3inch |
Transmission Power | 17~20dBm |
Transmission Range | 1200ft (No obstacles, no interference) |
Power Consumption | 4.5Watt (Typical) |
Operating Environment Temperature | -10~40℃ |
Dimensions | 105mmx66mmx32mm (Antennas not included) |
Weight | 210g (Antennas not included) |
Projects | Receiver |
Video Output | SDI/HDMI |
SDI Output Format | 1080p 24/25/30/50/60fps Level A |
HDMI Output Format | 1080p 24/25/30/50/60fps |
DC Port | 5.5mmx2.1mm center positive |
DC Voltage | 7.4~16.8V |
OLED Display | 1.3inch |
Power Consumption | 3.5Watt (Typical) |
Operating Environment Temperature | -10~40℃ |
Dimensions | 105mmx66mmx32mm (Antennas not included) |
Weight | 210g (Antennas not included) |
In the Box
- Accsoon CineView SE Multi-Spectrum Wireless Video Transmission System
- CineView SE Transmitter
- CineView SHE Receiver
- Shoe Mount
- Limited 1-Year Warranty
